High Airflow Mini-pleat HEPA Filter | Energy-Saving V-Bank Design for Industrial HVAC Systems
Maximize your energy efficiency with the Chuqi High Airflow Mini-pleat HEPA Filter. Specially engineered for large-scale ventilation, this V-bank mini-pleat filter combines a compact profile with a massive surface area to handle higher air volumes at a lower pressure drop. It is the premier choice for facilities looking to reduce power consumption while maintaining strict Class 100/1000 cleanroom standards.
Product Key Features
-
Filtration Class: H13 and H14 grades available, ensuring 99.99% efficiency.
-
Airflow Capacity: Optimized for large air flow requirements, supporting velocities up to 2.5m/s.
-
Initial Resistance: Ultra-low profile of $\le$220Pa even at high flow rates.
-
Operational Limits: Reliable performance up to 80°C and 80% humidity.
Material & Craftsmanship
-
Filter Media: Premium sub-micron fiber glass paper for high dust holding capacity.
-
Separator: Precision Hot-melt technology beads to ensure perfect airflow channels.
-
Frame: Reinforced anodized aluminum alloy or plastic V-bank frames.
-
Sealant: Professional gel-glue (Polyurethane) for 100% leak-proof security.
Applications
-
Data Center Cooling: High-efficiency filtration for Data Centers to prevent dust accumulation on servers without restricting airflow.
-
Automotive Clean Paint Lines: Essential for Car Spray Booths and coating lines requiring large volumes of clean, laminar air.
-
Large-Scale Food Processing: Provides sterile air for Mass Production Bottling Lines and large-scale dairy packaging zones.
-
Industrial AHU Units: Perfect for Air Handling Units (AHU) in large manufacturing plants to extend the life of terminal filters.
-
Battery Gigafactories: Supports the high-volume air turnover required in Lithium Battery Manufacturing dry rooms.
-
Commercial Building Air Quality: Premium filtration for high-rise Office Ventilation Systems and luxury shopping malls.
-
Chemical Processing Plants: Protects sensitive chemical reactions from airborne contaminants in Large-scale Laboratories.
Competitive Comparison
| Feature | Chuqi Eco-Flow Mini-Pleat | Standard Deep-Pleat Filters | The Chuqi Advantage |
| Air Volume | High Airflow Capacity (up to 4000 m3/h). | Limited to lower volumes per unit. |
Fewer Units Required: Lower initial installation cost.
|
| Energy Usage | Low Resistance Design (≤220Pa). | Higher pressure drop, higher energy. |
Lower Power Bills: Significant HVAC energy savings.
|
| Space Efficiency | Compact V-Bank / Slim Profile. | Bulky and heavy frames. |
Flexible Installation: Fits in tight HVAC plenum spaces.
|
| Lifespan | Large Dust Holding Capacity. | Standard media surface area. |
Reduced Maintenance: Fewer filter change-outs per year.
|
Specifications
| External dimensions
(mm) |
Rated air volume
(m³ / h) |
initial resistance
(Pa) |
efficiency
(%) |
Filter media |
| 610 × 610 × 69 | 600-1000 | ≤ 220 | 95-99.99995 | Fiberglass
|
| 760X610X69 | 800-1200 | ≤220 | 95-99.99995 | |
| 915×610×69 | 1000/1500 | ≤220 | 95-99.99995 | |
| 1170×570×69 | 1100/1800 | ≤220 | 95-99.99995 | |
| 1220×610×69 | 1200/2000 | ≤220 | 95-99.99995 |
Chuqi Eco-Flow Series is built upon our expertise in energy-saving filtration technology. We specialize in designing mini-pleated air filters that solve the conflict between high airflow and high energy costs. By utilizing advanced hot-melt technology and high-precision aluminum alloy profiles , Chuqi delivers industrial-grade filters that are both ultrathin and lightweight while offering the highest structural integrity. Our 100% individual testing protocol ensures that every large-airflow unit meets the most rigorous safety standards.
Frequently Asked Questions
Q1: How does the “V-bank” or High Airflow design save energy?
By increasing the surface area of the fiber glass paper , the filter reduces initial resistance. This allows your HVAC fans to move more air with less power, leading to lower operational costs.
Q2: Is this filter suitable for high-humidity industrial environments?
Yes. The materials are rated for 80% humidity. The hot-melt beads and anodized aluminum frame are moisture-resistant, preventing media collapse.
Q3: Can the High Airflow Mini-pleat be used in SMT lines?
Absolutely. It provides the good uniformity winds required for Surface Mount Technology (SMT) while handling the large air turnover needed in these electronics workshops.
Q4: How do you guarantee the seal in high-velocity airflow?
We use professional-grade gel-glue sealant which creates a hermetic bond between the frame and media, ensuring zero air bypass even at peak airflow.
Q5: What is the service life compared to a standard HEPA filter?
Due to its optimized pleat density and large dust holding capacity, the Eco-Flow series typically lasts 1.5 to 2 times longer than standard filters in similar industrial conditions.
